Paragon Double Barrel KM14 Pro Knife Oven
$5,339.25Regular price$5,650.00
Save $310.75- Talk to a kiln expert before you buy. Call or text: 470-264-3563
Configure your kiln
Not sure? Call 470-264-3563
Add it to this order Upgrades & add-ons
Kiln Controller
A digital controller in its own wall-mounted box. It runs the kiln through a power cord, away from the kiln's heat.
Who needs it: Kilns with a manual or worn-out controller, or studios that want a different interface. Pick the voltage and amperage that match your kiln.
Skip it if this kiln already has a programmable controller built in. Most buyers do not need a second one; ask us about the factory touchscreen upgrade instead.
Full details → · Not sure? Call 470-264-3563
A digital controller in its own wall-mounted box. It runs the kiln through a power cord, away from the kiln's heat.
Who needs it: Kilns with a manual or worn-out controller, or studios that want a different interface. Pick the voltage and amperage that match your kiln.
Skip it if this kiln already has a programmable controller built in. Most buyers do not need a second one; ask us about the factory touchscreen upgrade instead.
Full details → · Not sure? Call 470-264-3563
A digital controller in its own wall-mounted box. It runs the kiln through a power cord, away from the kiln's heat.
Who needs it: Kilns with a manual or worn-out controller, or studios that want a different interface. Pick the voltage and amperage that match your kiln.
Skip it if this kiln already has a programmable controller built in. Most buyers do not need a second one; ask us about the factory touchscreen upgrade instead.
Full details → · Not sure? Call 470-264-3563
Your add-onsNone selected
$0
See your delivered price
Enter your ZIP to see freight and your delivered total, including anything ticked above.
Secure checkout · No sales tax outside Georgia
Buy with confidence
When it ships & how it's delivered · freight to your door
Paragon builds most kilns to order once your order is placed. We email your confirmed ship date and tracking.
- The freight carrier calls you to book a delivery window.
- Delivery is curbside with a liftgate. Have a helper or hand truck to move it inside.
- Check the crate before you sign. Note any damage on the receipt and send us photos.
Enter your ZIP in "See your delivered price" above the Add to cart button to see freight and your delivered total.
Authorized Paragon dealer · full factory warranty
Brand new and shipped direct from Paragon, so it carries Paragon's full factory warranty. If something goes wrong, call us and we handle the claim with the factory for you.
Warranty terms are in the Warranty and support section below.
Returns: request within 15 days, unused
Because kilns are heavy and often built to order, returns are limited, so we'd rather help you pick the right one up front:
- Ask within 15 days of purchase or 2 days after delivery, whichever comes first. We issue a return authorization (RA).
- It must be new, unused (beyond the factory test fire) and in its original packaging.
- A restocking fee of at least 25% applies, up to 50% on custom, 3-phase or made-to-order units. Return freight is on the buyer unless we made an error.
- Damaged in transit? Note it on the delivery receipt, send us photos and we'll help with the freight claim.
Will it work in my space? Power check
Not included: Paragon Knifemaking Heat Treating Kit (gloves, tongs, blade holders, firebrick supports) and gas inlet/flowmeter, both optional upgrades. Requires 240V, 20 amps, with a NEMA 6-30 receptacle. Call us to confirm the plug type for your shop before ordering.
Most 240V kilns need their own circuit and the matching outlet, installed by an electrician. Homes are usually 240V; schools and commercial buildings are often 208V, so pick the voltage that matches your panel.
Send us a photo of your breaker panel or outlet and we'll confirm before your kiln is built: 470-264-3563 (call or text).
More ways to save · wire, school & military pricing
- Pay by bank wire: 3% off the subtotal, freight included.
- Schools, studios & bulk orders: purchase orders welcome, quoted before funding is approved.
- Military, veterans & first responders: 5% off your whole order.
- Price match: found a lower delivered price online? We'll match it.
Not ready yet? Email me this build + a delivered quote
Talk to a kiln expertGet your exact delivered price
- Freight to your ZIP and the current lead time on this model
- Found a lower delivered price online? We'll match it
- Voltage, breaker and venting answers before you order
Real people, 8am-8pm ET, 7 days. Texts and messages answered within the hour.
Prefer email? Get a written delivered quote →Paragon Double Barrel KM1...
$5,339.25
Overview
Paragon · Heat Treating Oven · Double Barrel Knife Kiln
Paragon Double Barrel KM14 Pro Knife Oven
The Double Barrel KM14 Pro features one extra-wide firing chamber with 2-zone control that lets you heat treat more blades in a single load, dramatically increasing production capacity for professional knifemakers. Ultra-fast heat-up capability reaches 500°F in minutes thanks to space-age ceramic fiber construction, reducing wait times and maximizing throughput. Built in the USA with precision engineering for repeatable hardening and tempering cycles across high-carbon, tool steels, and stainless alloys.
Max Temperature2350°F
Chamber ConfigurationOne 13.25" W × 5.25" H × 14.5" D chamber
Voltage240V
Heat-Up SpeedReaches 500°F in minutes
What’s included
The oven, assembled and wiredParagon builds and wires it at the factory. The door style you chose is already fitted: a spring-assisted drop door or a side-swing door, both standard at the same price.
Digital controller, factory-installedParagon fits and wires the controller before the kiln leaves the factory. Paragon has been renaming and replacing its controller line and dealer listings are out of date at different dates, so we do not print a model name here. We confirm the exact controller with Paragon when you order.
Type-K thermocouple, installedFitted at the factory and wired to the controller. Type-K is standard across the current Paragon range.
Door safety switchWired in at the factory. It cuts power to the elements the moment you open the door, so you are not reaching into a live chamber.
Cord and plugParagon ships this kiln with a cord and plug. The receptacle type changes with the voltage option you order, so we confirm the exact plug — or whether your configuration is wired direct instead — with Paragon before the order goes in.
Printed manualsA printed instruction manual for the kiln and a separate guide for the controller. Warranty registration is done online at Paragon, and we do not promise a printed warranty card in the crate because we could not confirm one is packed.
Paragon limited warranty — one yearOne year from purchase on this model, per Paragon's published warranty schedule. Paragon does not warrant the Type-K thermocouple, so treat that as a wear part. Keep your proof of purchase.
Not includedNo shelves, posts or kiln furniture ship with a knife oven. The Knifemaker's Heat Treating Kit — four knife holders, eight firebrick supports, a heat treating fork and hot gloves — is a separate purchase, and so are the upgraded touchscreen controller and the gas-inlet option.
Key features
Double barrel ceramic fiber construction
One extra-wide 13.25" W × 5.25" H × 14.5" D firing chamber (0.58 cu ft) with ultra-fast heat-up 2.5" ceramic fiber insulation for efficient heat treating operations
Sentinel touchscreen controller with 2-zone control
Front and rear thermocouples regulate two heating zones for even temperature along the full length of the chamber
Guillotine door
Spring-assisted vertical door lifts up and away for easy one-handed front loading and efficient workflow in production environments
Heavy-duty element system
Kanthal A-1 heating elements designed for rapid temperature cycling and extended service life under demanding heat treating conditions
Stainless steel exterior shell
Durable 20-gauge stainless steel jacket protects internal components and provides professional appearance for studio or production shop
Optional gas inlet for atmosphere control
Order with the optional gas inlet and flowmeter to connect nitrogen, argon, or controlled atmosphere systems to prevent oxidation and decarburization
Technical specifications
ModelKM14 Pro Double Barrel
Chamber dimensions13.25" wide × 5.25" high × 14.5" deep
Temperature zones2 (front and rear thermocouples)
Overall exterior dimensions27" wide × 14" deep × 22" high
Chamber volume0.58 cubic feet
Insulation typeCeramic fiber, 2.5" thickness
Maximum temperature2350°F
Voltage options240V single phase
Amperage and breakerConfirm with us before installation
Element typeKanthal A-1 high-temperature wire
ControllerSentinel touchscreen, 2-zone (one controller)
Atmosphere capabilityOptional gas inlet and flowmeter for inert gas or controlled atmosphere
Shipping weightApproximately 110 lbs
Country of manufactureMade in USA
Optional accessories
Nitrogen gas regulator kit
Complete regulator and hose assembly for connecting nitrogen tanks to the optional gas inlet, providing controlled inert atmosphere to prevent oxidation during heat treating
Stainless steel blade racks
Custom-sized vertical racks maximize chamber capacity and ensure proper spacing for even heat distribution during hardening and tempering cycles
Type K thermocouple replacement
Spare high-temperature Type K thermocouple with ceramic protection tube for accurate temperature measurement and controller feedback
Ceramic fiber repair kit
High-temperature ceramic fiber blanket material and adhesive for maintaining chamber insulation integrity and extending oven service life
Digital pyrometer with probe
Independent temperature verification system with high-accuracy Type K probe for validating heat treat temperatures and controller calibration
Quench oil tank with temperature control
Heated quench oil system maintains optimal oil temperature for consistent hardening results with tool steels and high-carbon alloys
Controller upgrade
Genesis Touchscreen — Bartlett InstrumentsRecommended
Upgrade to the Genesis touchscreen controller for advanced heat treating programs, expanded data logging, and intuitive programming with a full-color 4.3" display that simplifies complex multi-step hardening and tempering cycles.
- Store up to 250 custom heat treat programs with unlimited segments for precise austenization, quench timing, and tempering schedules
- Full-color 4.3" capacitive touchscreen displays real-time temperature graphs and remaining cycle time for both ramp and hold segments
- Data logging records complete firing history with time/temperature data exportable via USB for quality control documentation and heat treat certifications
- Delay start programming allows you to schedule overnight or weekend cycles to maximize oven utilization without supervision
- Built-in steel library with pre-programmed heat treat cycles for common knife steels including 1095, O1, D2, 440C, and CPM alloys
- Advanced alarm functions notify you of temperature deviations, thermocouple failures, or element malfunctions to prevent blade damage
Common questions
What types of steel can I heat treat in the KM14 Pro?
The 2350°F maximum temperature handles all common blade steels including high-carbon alloys (1095, 1084, 5160), tool steels (O1, A2, D2), and most stainless steels (440C, AEB-L, 154CM). For specialty steels requiring higher austenitizing temperatures like CPM S35VN or CPM M4 (typically 1900-2150°F), this oven provides adequate overhead. The extra-wide chamber lets you harden more blades per load, streamlining your workflow for production knifemaking.
Do I need the optional gas inlet for atmosphere control?
The gas inlet and flowmeter are an optional factory upgrade, but highly recommended for professional results. Running nitrogen or argon through the chamber during heat treating prevents oxidation and decarburization, eliminating scale formation and preserving surface carbon content for optimal edge performance. If you're working with high-alloy stainless steels or want bright, scale-free finishes, connecting an inert gas system significantly reduces post-heat-treat grinding and finishing time. You'll need a standard industrial gas regulator and appropriate hose fittings (available as accessories).
What controller comes standard and can it handle complex heat treat cycles?
The KM14 Pro Double Barrel includes one Sentinel touchscreen controller with 2-zone control and programmable ramp-hold capabilities, allowing you to create multi-step heat treat programs for precise austenitizing, soak times, and tempering cycles. Its front and rear thermocouples help keep the temperature even along the chamber. For advanced features like USB data logging or expanded program storage, you can upgrade to the Genesis touchscreen controller, which includes pre-programmed cycles for common knife steels.
How does the Double Barrel KM14 Pro compare to single-chamber knife ovens?
The Double Barrel keeps the 14.5-inch depth of the KM14 Pro but has a much wider chamber (13.25 inches), so you can load more blades side by side without needing additional electrical circuits or workspace. It is one chamber with one 2-zone controller, so everything in a load runs the same program; the two zones simply keep the temperature even from front to back. For full-time knifemakers or small production shops, the extra capacity typically pays for itself in increased throughput.
Is this purchase covered under warranty, and does it matter where I buy it?
Paragon provides a one-year limited warranty on the KM14 Pro, but warranty coverage is valid only when purchased through authorized dealers like Peach State Pottery. You must register your oven within 30 days of delivery to activate warranty protection. Purchasing from unauthorized sellers or third-party marketplaces typically voids manufacturer warranty coverage and may result in receiving older inventory, modified units, or lacking technical support from Paragon's heat treating specialists. As an authorized dealer, we ensure you receive current-production units with full factory support and can assist with warranty claims if issues arise.
Not sure if the KM14 Pro is the right heat treating oven for your shop?
Our kiln specialists can help you compare chamber sizes, voltage requirements, and production capacity needs—or discuss atmosphere systems and steel-specific requirements.
