Paragon CS14D Dual Clam Shell Glass Fusing Kiln
$2,619.00
- 15-day returns
- No sales tax outside Georgia
- Made in USA
Ways to save
Choose your build
Built to order.
Already built, not made to order, so there is nothing else to configure. We confirm the lead time in writing before you are charged.
Lead time is confirmed in writing before you are charged.
Paragon CS14D Dual Clam S...
$2,619.00
Overview
Paragon · Electric Kiln · Glass Fusing
Paragon CS14D Dual Clam Shell Glass Fusing Kiln
The CS14D adds an independent top lid to the clamshell body, giving you two ways into the same 14" square chamber — lift the top lid for quick loading, or swing the full clamshell open for larger pieces. The SENTINEL Touch Xpress touchscreen controller and counterweight-assisted lift make daily use straightforward.
Chamber size14" square
DesignDual opening (lid + clamshell)
Power120V Single-Phase
ControllerSENTINEL Touch Xpress
What’s included
The kiln, assembled and wiredParagon builds, wires and tests it at the factory, so it arrives ready to connect to power.
Built-in base with mar-proof feetThe steel base is part of the kiln, with mar-proof feet underneath. Nothing separate ships for it.
Digital controller, factory-installedParagon fits and wires the controller before the kiln leaves the factory. Paragon has been renaming and replacing its controller line and dealer listings are out of date at different dates, so we do not print a model name here. We confirm the exact controller with Paragon when you order.
Type-K thermocouple, installedFitted at the factory in a high-nickel sheath and wired to the controller.
Lid interrupt safety switchParagon fits a switch that cuts power to the elements when the kiln is opened, and the On/Off switch is on the kiln as well.
Cord and plugParagon ships this kiln with a cord and plug. The receptacle type changes with the voltage option you order, so we confirm the exact plug — or whether your configuration is wired direct instead — with Paragon before the order goes in.
Paragon limited warrantyParagon limited warranty — we confirm the term for your model before you order. Paragon's published schedule and its dealers' listings disagree on the term for this kiln, so we will not print a number here that we cannot stand behind.
Not includedNo shelves or posts ship with a clam shell. The window, bead doors, the ceramic fiber top upgrade, shelf kits and the mercury relay are separate options at order time.
Key features
SENTINEL Touch Xpress controller
Touchscreen controller for fusing and slumping schedules
Dual-opening design
Independent top lid plus full clamshell body access
Counterweight-assisted lift
Smooth, controlled opening for both the lid and clamshell
Welded steel lid cover with reversible firebrick bottom
Flip the floor when one side wears for extended service life
Dual mechanical relays
Reliable switching built for repeated daily firings
Cool-touch wooden handles
Comfortable handles on both the lid and body
Technical specifications
ModelCS14D
Chamber14" square interior
DesignDual-opening (independent top lid + full clamshell)
Voltage120V, single-phase
ControllerSENTINEL Touch Xpress touchscreen
ThermocoupleStainless steel-sheathed
Made inUSA (Mesquite, Texas)
Optional accessories
Furniture kit
Kiln shelf, posts, and glass separator sized for the 14" chamber
Digital pyrometer
Independent temperature monitoring for precise fusing and slumping
Kiln wash / shelf primer
Protects shelves from glass runout and makes cleanup easier
Replacement heating elements
Spare element set for future maintenance
Common questions
Why choose the CS14D over the CS14S?
The CS14D adds an independent top lid to the same clamshell body, so you can quickly lift the lid for small loads or swing the full clamshell open for larger pieces without waiting on the whole shell every time.
What's the benefit of the dual-opening design day to day?
Quick top-lid access speeds up routine loading and checking on firings, while the full clamshell opening stays available whenever you need to load bigger or awkward pieces.
What colors is the CS14D available in?
It's available in 8 color options at no additional cost, so you can match your studio's look.
Is the warranty valid if I buy from Peach State Pottery?
Yes. Peach State Pottery is an authorized Paragon dealer, so your CS14D comes with Paragon's full one-year manufacturer's warranty. Register your kiln within 30 days of delivery to activate coverage.
