Jen-Ken AF3C 15/13 "The Emerge" Ceramic Kiln - 240V, Cone 8, 15" x 13"

Jen-KenElectric KilnSKU JENKEN-AF3C-15-13
$1,869.00Regular price$1,969.00
Save $100.00

  • 15-day returns
  • No sales tax outside Georgia
  • Made in USA
Configure your kiln Not sure? Call 470-264-3563
Furniture kit

15/13 is the size our records hold for this kiln. Change it here if your chamber is a different size, or call us and we will check it with you.

  • Orton VentMaster Kiln Vent SystemFan assembly, Collection cup, High-temperature hose, Drill bit, Stud, Printed manual, Orton...

    Shipping is chosen at checkout: free curbside freight, or Freight + Liftgate Delivery for $139.

    Freight is free and curbside, without a liftgate: plan on a loading dock, a forklift or 2 or more helpers. Or choose Freight + Liftgate Delivery at checkout, $139.

    Jen-Ken AF3C 15/13 "The E...
    $1,869.00
    Call

    Overview

    Jen-Ken · Ceramic Kiln · AF3C Series Jen-Ken AF3C 15/13 "The Emerge" Ceramic Kiln Model AF3C 15/13 · 240V · 15" x 13" chamber · Cone 8 / 2,300°F The Emerge is the kiln Jen-Ken built for the person moving out of a community studio and into their own space. It is 1.4 cubic feet, draws 22 amps on 240V, and runs from the same class of 30-amp circuit a household dryer uses — so it usually goes in without a service upgrade. Jen-Ken rates it for ceramics, pottery and glass, which makes it a reasonable single kiln for someone who does both. It is small: a 15" x 13" chamber fires a real load of mugs, not a body of large work.
    Max Temp2,300°F (Cone 8)
    Chamber15" x 13"
    Capacity1.4 cu ft
    Power240V · 22A
    What’s included
    The kiln, built and wiredCase, elements, thermocouple, switch box and wiring are all fitted and tested at the factory. It ships crated on a pallet by motor freight.
    The controller you orderJen-Ken fits the controller you pick when the order goes in — the AF3C 3-button, the AutoFire 12-button, the AutoFire Slide touchscreen or the TAP touchscreen. Each one is a different price, so the controller that ships is the one on your order rather than a fixed model.
    Cord and plug — NEMA 6-30PJen-Ken wires the cord and plug at the factory. You supply the matching receptacle on its own circuit — the breaker size and wire gauge for this model are in the specifications below.
    Instruction manualJen-Ken's printed manual, including firing schedules and their electrical requirements.
    2-year limited warrantyJen-Ken's brick-kiln warranty, direct from the factory to the original purchaser.
    Not included — kiln furnitureNo shelves, posts or kiln wash in the crate. Jen-Ken prices a furniture kit for this model as a separate line, and we stock the pieces on our accessories pages. Solid-state relays are a paid upgrade rather than standard.
    Key features
    Dual-media buildJen-Ken lists this model for ceramics, pottery and glass, so it does not have to be a clay-only kiln.
    Built to order in FloridaAssembled in Jen-Ken's own Lakeland shop rather than drop-shipped from a distributor.
    Chamber size15" x 13" — 1.4 cu ft. That is the space you actually have to load.
    Maximum temperatureRated to 2,300°F (1,260°C). Jen-Ken gives it as Cone 8.
    Technical specifications
    ModelAF3C 15/13 "The Emerge"
    Kiln functionCeramics, pottery, glass
    Chamber dimensions15" x 13"
    Cubic feet1.4 cu ft
    Maximum temperature2,300°F (1,260°C)
    Cone ratingCone 8
    Voltage240V
    Amperage22A
    Wattage5,280W
    PhaseSingle phase
    ReceptacleNEMA 6-30R
    Breaker (fuse) size30A
    Circuit wire gauge#10
    Element placementSide-fired
    LoadingTop-loading
    ControllerOrton AutoFire AF3C 3-button
    Overall dimensions30" x 30" x 18"
    Kiln weight100 lbs
    Estimated shipping weight160 lbs
    Shipping dimensions32" x 32" x 41"
    Shipping methodMotor freight
    Warranty2-year limited (Jen-Ken)
    Warranty: Two-year limited warranty from Jen-Ken Kilns to the original purchaser on brick kilns, covering defects in materials and workmanship and limited to repair or replacement of defective items. Elements and thermocouples carry their own two-year coverage; thermocouples are not warranted against breakage. The Orton controller is covered by Orton's own warranty. Keep your proof of purchase. Peach State Pottery is an authorized Jen-Ken dealer.
    Optional accessories
    Kiln shelves and postsJen-Ken's own shelves and posts are sized to this chamber. We stock them alongside the kiln.
    Kiln washShelf primer keeps glaze off your shelves. Worth adding to a first order.
    Furniture kitA matched set of shelves and posts for this chamber, cheaper than buying the pieces individually.
    208V or three-phase buildJen-Ken can build most ceramic models for 208V, and some for three phase, to order. Contact us for a quote — there is no published spec for those builds.
    Common questions
    What electrical circuit does it need?240V single phase, 22A draw. Jen-Ken pairs it with a NEMA 6-30R receptacle, a 30A breaker and #10 circuit wire. That is dryer-class power, but the kiln needs its own dedicated run. A kiln is a continuous load, so have a licensed electrician confirm the breaker and wire against your local code before delivery. Jen-Ken also notes that runs over 30 feet from the breaker may need the next heavier gauge.
    What can it actually fire?Jen-Ken designs it to fire up to cone 8 at 2,300°F, which covers low-fire, mid-fire stoneware and porcelain. It will not reach cone 10. Jen-Ken also lists it for glass, so fusing and slumping schedules are within range.
    Is 1.4 cubic feet enough?It depends what you make. It is a genuine working kiln for mugs, bowls and small sculpture, and it will fire a full load rather than a couple of test tiles. If you throw platters or tall vases, or you want to fire a month of production at once, look at the 1822 or larger.
    One note on Jen-Ken's own pageJen-Ken's page carries a heading mentioning cone 9 while the body copy says it is designed to fire up to cone 8. We publish cone 8, which is the rating in the body text and the one consistent with a 2,300°F kiln.
    How long until it ships?Jen-Ken builds to order in Lakeland, Florida. Their own guidance is that kilns can take several weeks to months depending on the production queue. Call us and we will get you the current estimate before you commit.
    What actually comes in the crate?The section at the top of this page is that list, and it comes from Jen-Ken’s own dealer price sheet for this model rather than from a guess. Kiln furniture is the thing most people assume is in the crate and is not — Jen-Ken prices the shelves and posts as a separate kit. Call or email us if you want the crate confirmed against your build before you order.
    Does buying from Peach State Pottery affect my warranty?No. We are an authorized Jen-Ken dealer, so the factory two-year warranty applies exactly as it would buying direct. Keep your proof of purchase.
    Not sure if The Emerge is big enough? We are authorized Jen-Ken dealers based in Georgia. Tell us what you make and what power you have available, and we will tell you straight whether this is the right kiln — including when a cheaper one would do.
